X13 Systems

• Key Features/Applications: Industrial Automation, Retail, Digital Signage, Kiosk, Interactive info system, Smart Medical Expert Systems, IoT Gateway for Smart Factory, Smart Building, Security and Surveillance
• CPU: Single Intel® Celeron® 7305E Processor, up to 5 Cores
• Chassis: Fanless Embedded
• Drive: Up to 1x M.2 SATA B-Key 2242/2280 + 1x M.2 NVMe M-Key 2242/2280 + 1x M.2 Slot (E-Key 2230; USB 2.0)
• RAM: Up to 64GB of DDR5 Non-ECC SO-DIMM in 2 DIMM Slots
• Network Ports: 2x 2.5GbE RJ45 LAN Ports
• Wi-Fi enabled system. Support for Wi-Fi 4, 5, 6, 6E R2, and Bluetooth® 5.3

• Key Features/Applications: Entry-Level System, Designed for Small and Medium-sized Business Applications
• CPU: Single Intel® Xeon® E-2400 Series Processors or 12th Generation Pentium® Processors, up to 8 Cores
• Chassis: Compact Mini-Tower
• Drive: Up to 4x 3.5" Front Hot-Swap PCIe 4.0 x4 NVMe/SAS/SATA Drive Bays. (NVMe/SAS Optional)
• RAM: Up to 64GB of DDR5 ECC UDIMM in 2 DIMM Slots
• Network Ports: 2x 1GbE RJ45 LAN Ports

• Key Features/Applications: Storage, Application and Centralized Data Backup System Applications, IPMI for Remote Management, Entry-Level Server for SOHO and SMB
• CPU: Single Intel® Xeon® E-2400 Series Processors or 12th Generation Pentium® Processors, up to 8 Cores
• Chassis: Mini-Tower
• Drive: Up to 4x 3.5" Internal SATA Drive Bays
• RAM: Up to 128GB of DDR5 ECC UDIMM in 4 DIMM Slots
• Network Ports: 2x 1GbE RJ45 LAN Ports

• Key Features/Applications: High Performance Computing (HPC), VDI, AI/Deep Learning Training, Media/Video Streaming, Cloud Gaming, Animation and Modeling, Design & Visualization, 3D Rendering, Diagnostic Imaging, AI Training
• CPU: Dual 5th/4th Gen Intel® Xeon® Scalable Processors, up to 64 Cores
• Chassis: Full-Tower/5U Rackmount
• Drive: Up to 8x 3.5" Front Hot-Swap NVMe/SATA/SAS Drive Bays
• RAM: Up to 4TB of DDR5 ECC RDIMM in 16 DIMM Slots
• GPU: Up to 4 Double-Width or Single-Width GPUs
• Network Ports: 2x 10GbE RJ45 LAN Ports
• Power Supply: 2x 2000W Redundant (1 + 1) Titanium Level Power Supplies

• Key Features/Applications: Enterprise Server, iSCSI SAN, HPC, Data Center, Database Processing & Storage, Corporate Database, Appliance Optimized Storage Building Blocks
• CPU: Dual 5th/4th Gen Intel® Xeon® Scalable Processors, up to 270W TDP
• Chassis: 2U
• Drive: Up to 12x 3.5" Front Hot-Swap SAS/SATA + 2x 2.5" Hot-Swap SATA Drive Bays
• RAM: Up to 4TB of DDR5 ECC RDIMM in 16 DIMM Slots
• Network Ports: 2x 10GbE RJ45 LAN Ports
• Power Supply: 2x 1200W Redundant Titanium Level Hot-Plug Power Supplies
• For assistance with RAID configuration, please Contact Us.

• Key Features/Applications: Enterprise Server, iSCSI SAN, HPC, Data Center, Database Processing & Storage, Corporate Database, Appliance Optimized Storage Building Blocks
• CPU: Dual 5th/4th Gen Intel® Xeon® Scalable Processors, up to 270W TDP
• Chassis: 4U
• Drive: Up to 36x 3.5" Hot-Swap SAS/SATA + 2x 2.5" Hot-Swap SATA Drive Bays
• RAM: Up to 4TB of DDR5 ECC RDIMM in 16 DIMM Slots
• Network Ports: 2x 10GbE RJ45 LAN Ports
• Power Supply: 2x 1600W Redundant Titanium Level Hot-Plug Power Supplies
• For assistance with RAID configuration, please Contact Us.

• Key Features/Applications: Virtualization, Cloud Computing, Enterprise Server, Data Center Optimized, Entry GPU server, Rack Workstation
• CPU: Single Intel® Xeon® E-2400 Series or 12th Generation Pentium® Processors, up to 95W TDP
• Chassis: 1U
• Drive: Up to 4x 3.5" Front Hot-Swap SATA Drive Bays
• RAM: Up to 128GB of DDR5 ECC UDIMM in 4 DIMM Slots
• Network Ports: 2x 1GbE RJ45 LAN Ports
• Power Supply: 600W Redundant Titanium Level Power Supplies

• Key Features/Applications: General Purpose, Small Business, Web Hosting, Networking, Encoding/Decoding, Email/Firewall/Print Server
• CPU: Single Intel® Xeon® E-2400 Series or 12th Generation Pentium® Processors, up to 95W TDP
• Chassis: 1U
• Drive: Up to 4x 3.5" Front Hot-Swap SATA Drive Bays
• RAM: Up to 128GB of DDR5 ECC UDIMM in 4 DIMM Slots
• Network Ports: 2x 1GbE RJ45 LAN Ports
• Power Supply: 600W Redundant Titanium Level Power Supplies

• Key Features/Applications: Cloud Computing, Web Hosting, VM, Online Game Server Hosting, IT Infrastructure, Web Cache, Social Networking
• CPU: Single Intel® Xeon® E-2400 / Pentium® G7400 and G6400T Processors, up to 95W TDP
• Chassis: 3U / 8 Node
• Drive: Up to 2x 3.5" Front Hot-Swap NVMe/SATA/SAS Drive Bays Per Node
• RAM: Up to 128GB of DDR5 ECC UDIMM in 4 DIMM Slots Per Node
• GPU: Up to 1 Single-Width GPU Per Node
• Network Ports: 1+1 Dedicated and Centralized IPMI LAN Ports Per Node
• Power Supply: 2x 2200W Redundant Titanium Level Power Supplies

* Complete systems only with all 8 nodes populated.

• Key Features/Applications: Web Server, Firewall Application, Cloud Computing, Compact Server, Data Center Optimized, Value IaaS, DNS & Gateway Servers, CDN, Edge Nodes
• CPU: Dual 5th/4th Gen Intel® Xeon® Scalable Processors, up to 32 Cores
• Chassis: 1U
• Drive: Up to 4x 3.5"/2.5" Hot-Swap and Tool-Less NVMe/SATA/SAS Drive Bays
• RAM: Up to 4TB of DDR5 ECC RDIMM in 16 DIMM Slots
• GPU: Up to 2 Low-Profile GPUs
• Network Ports: 2x AIOM (OCP 3.0) Slots with NCSI
• Power Supply: 2x 860W Redundant Titanium Level Power Supplies
