Supermicro SYS-222HA-TN 2U Rackmount X14 DP Hyper Server

SuperServer SYS-222HA-TN: High-Performance 2U Rackmount Hyper Server for AI and HPC

The Supermicro SuperServer SYS-222HA-TN is a versatile 2U rackmount server optimized for AI, virtualization, HPC, and data analytics. Powered by the X14DBM-AP motherboard and dual Intel® Xeon® 6900-Series processors, with up to 128 cores and 256 threads, it delivers exceptional performance for demanding workloads.

Exceptional Memory Scalability and Flexible Expansion

Featuring 24 DDR5 DIMM slots, it supports up to 6TB of memory, ensuring rapid data processing. Storage is highly flexible with up to 24 hot-swap 2.5" NVMe/SAS/SATA bays and dual M.2 PCIe 5.0 NVMe slots. Expansion options include up to 4 PCIe 5.0 x16 or 8 PCIe 5.0 x8 slots, supporting up to 4 double-width GPUs and 2 AIOM (OCP 3.0) networking slots for high-speed connectivity.

Advanced Thermal Design and Hardware-Level Security

Designed for reliability, it offers dual redundant power supplies, and up to six counter-rotating fans, and optional liquid cooling. Advanced management via IPMI 2.0, KVM-over-LAN, and PC health monitoring ensures seamless operation. Security is robust with TPM 2.0, Secure Boot, and cryptographically signed firmware, safeguarding critical data.

This energy-efficient server maximizes uptime and scalability for enterprise and cloud environments. Elevate your infrastructure with Supermicro’s SYS-222HA-TN.

Key Features

• Dual Intel® Xeon® 6900 processors supporting up to 500W TDP for heavy compute
• Up to 6TB memory capacity across 24 DIMMs supporting DDR5 RDIMM or MRDIMM
• Supports up to 4 double-width or 8 single-width GPUs
• Up to 2 AIOM slots (OCP NIC 3.0) for flexible high-speed networking
• Flexible 2.5" hot-swap storage supporting up to 24 NVMe/SAS/SATA bays plus dual M.2
• Advanced cooling options with counter-rotating fans and optional liquid cooling
• Enterprise security & management featuring TPM 2.0, secure boot, and IPMI 2.0
