Supermicro 500W/600W 1U Redundant Power Supply (PWS-504P-1R2)

  • Designed for Supermicro 1U Server
  • Redundant PSU with PMBus 1.2 Support for Remote Management
  • 80 Plus Platinum Efficiency
  • Supermicro Certified
Buy More, Save More
In stock


The Supermicro PWS-504P-1R2 is an 80 Plus Platinum level redundant power supply capable of continuously supplying 500W/600W output power at 94%+ efficiency. Enjoy the simplicity of active power factor correction (PFC) and automatically correct AC input for a full range of voltages. This power supply is designed to not only provide you reliable power to your Supermicro server but also protects it from over voltage, over current and short circuiting via protective circuitry embedded into the unit. Rest easy knowing your hardware will be up and running with a mean-time between failure (MTBF) of greater than 250,000 hours and an LED indicator to keep you informed on normal/abnormal conditions for your PSU. This power supply is redundant to safe-guard your system from power failure and allows for hot-swap replacement to eliminate system downtime. All materials contained comply with RoHS requirements and is certified by Supermicro.

More Information
Total Power Output 500W/600W
Type Single
Type of Power Supply Power Supply
Form Factor 1U
Dimension (W x H x L) 54.5 x 40.25 x 322 mm
+5V -
+12V 42A (100-127Vac) 50A (200-240Vac)
+3.3V -
5V Standby 4A
+12V Standby -
Input Voltage Range 500W: 100-127Vac 600W: 200-240Vac 600W: 200-240Vdc
Input Frequency Range 50-60Hz
Input Current Range 100-127Vac / 6 – 4.5A 200-240Vac / 3.5 – 3A 200-240Vdc / 11 – 10A (CCC only)
Output Type Gold Finger
8Pin / 4Pin (12V) Connector -
PFC Yes, PMBus 1.2 support
Energy Efficiency 94%+
80 Plus Certification 80 Plus Platinum
Warranty 1 year warranty
Product Environmental Compliance RoHS and REACH compliant, details available upon request
Title Format Date
PWS-504P-1R2 Spec Sheet PDF Jan 2023
