Supermicro 1U WIO SuperServer (SYS-510P-WTR)
- Key Features/ Applications: Virtualization, Cloud Computing, Enterprise Server, Data Center Optimized
- CPU: Single 3rd Gen Intel® Xeon® Scalable processors
- Chassis: 1U / 1 Node
- Drive: 4 3.5" Hybrid NVMe/SATA Drive Bays
- RAM: 8 DDR4 DIMM Slots
- Network Ports: 2 10GbE LAN Ports
- Ships Within 3-5 Business Days
In stock
Unlock superior data center performance with the Supermicro SuperServer SYS-510P-WTR, a versatile 1U rackmount server tailored for virtualization, cloud computing, enterprise storage, and data center optimization. This high-density system boasts flexible I/O with 4 hot-swap 3.5" hybrid NVMe/SAS/SATA drive bays (configurable for PCIe 4.0 NVMe with controllers and cables) and 3 PCIe 4.0 expansion slots, supporting up to 1 single-width GPU for accelerated workloads. Ideal for scalable infrastructure, the SYS-510P-WTR delivers cost-effective reliability in a compact form, perfect for hybrid cloud environments and high-throughput applications.
Powered by a single 3rd Gen Intel® Xeon® Scalable processor (LGA-4189 socket) with up to 40 cores/80 threads, 270W TDP, and 60MB cache, it powers intensive tasks like database processing and AI inference effortlessly. Memory excels with 8 DIMM slots supporting up to 2TB of 3200MT/s 3DS ECC DDR4 RDIMM/LRDIMM (1.2V), plus Intel® Optane™ persistent memory for enhanced data persistence in virtualization scenarios. Storage shines with native SATA3 6Gbps RAID 0/1/5/10, optional SAS3/NVMe via controllers (e.g., AOC-S3108L-H8iR for RAID 0/1/5/6/10/50/60) and Intel VROC, complemented by 1x M.2 NVMe/SATA slot—ideal for robust RAID setups.
Expansion includes 2x PCIe 4.0 x16 FHFL slots and 1x PCIe 4.0 x16 LP slot (via risers), enabling seamless GPU integration for cloud-native computing. Networking is enterprise-ready with dual 10GbE RJ45 LAN ports (Intel® X550) and a dedicated 1GbE BMC IPMI port for remote management. Security is fortified with TPM 2.0 header, Silicon Root of Trust (NIST 800-193 compliant), secure boot, cryptographically signed firmware, and system lockdown to protect sensitive deployments.
Redundant Platinum 500W/600W PSUs (Titanium optional) pair with up to 5 counter-rotation PWM fans and air shrouding for optimal cooling (10-35°C operation), backed by comprehensive PC health monitoring for voltages, temperatures, and fans. The Intel® C621A chipset, AMI BIOS with 32MB SPI Flash, and ACPI power management ensure effortless integration.
Measuring 1.7" H x 17.2" W x 25.6" D (24 lbs net), the SYS-510P-WTR maximizes density for edge and core infrastructure. Elevate your setup with Supermicro's SYS-510P-WTR—unmatched efficiency, security, and scalability for tomorrow's demands.
| CPU | 3rd Gen. Xeon® Processor |
|---|---|
| Max Number of CPU | 1 |
| Specification | adsa |
| asa |
The Supermicro SYS-510P-WTR is a single-socket Intel Xeon “Ice Lake” generation server. In this generation, Intel’s newest processors offer a lot more for single-socket systems and Supermicro is taking advantage of the advancement.
This is a lot more than the 2Gb Internet connection we got! We deployed Supermicro 510P-WTR server for LAN cashing. 510P-WTR absolutely saved our bacon and the CPU usage is not even that high. It is surprising how easily 510P-WTR handled the download speeds with just a couple of NVMe drives.
