Supermicro 2U WIO SuperServer (SYS-522B-WR)

Elevate your data center with the Supermicro SuperServer SYS-522B-WR, a high-performance 2U Wide I/O (WIO) rackmount server optimized for AI, enterprise storage, and cloud computing. Engineered for flexibility, this robust system supports up to 8 hot-swap 3.5" SAS/SATA drive bays (with options for 4x 2.5" PCIe 5.0 x4 NVMe/SAS/SATA + 4x 3.5"/2.5" SAS/SATA) and up to 5 PCIe 5.0 expansion slots, delivering unmatched scalability for virtualization, database clusters, and high-density storage. Its compact design maximizes efficiency, making it ideal for businesses seeking cost-effective, future-proof solutions like entry-level GPU servers and networking appliances.

Powered by a single Intel® Xeon® 6 processor with up to 86 P-cores/172 threads or 144 E-cores (350W TDP, up to 336MB cache for P-cores or 108MB for E-cores), the SYS-522B-WR tackles demanding workloads like AI inference, web caching, and CDN applications with ease. It supports up to 2TB of 6400MT/s ECC DDR5 RDIMM across 8 DIMM slots, ensuring rapid data processing for mission-critical tasks. Storage versatility shines with native support for 8x 3.5" hot-swap bays (configurable for PCIe 5.0 NVMe with controllers and cables) and 2 M.2 PCIe 5.0 x2 slots for RAID-enabled boot drives (VROC supported). Optional controllers like the AOC-S3908L-H8iR enhance RAID performance for storage-intensive deployments.

Networking is seamless with dual 1GbE RJ45 LAN ports and a dedicated BMC IPMI port for remote management. Security is fortified with onboard TPM 2.0, Silicon Root of Trust, secure boot, and NIST 800-193-compliant runtime protections, safeguarding AI and cloud workloads. Maintenance is simplified with tool-less top-loading risers, up to 3 heavy-duty PWM fans with air shrouding, and comprehensive PC health monitoring for optimal cooling (10-35°C). Measuring 3.5" H x 17.2" W x 25.5" D, the SYS-522B-WR balances density and power.

From edge computing to storage headnodes, the SYS-522B-WR delivers reliability and scalability. Invest in Supermicro’s SYS-522B-WR to transform your infrastructure with cutting-edge performance and efficiency.
